HS3000-3008 Layer 2 Managed Gigabit Industrial Switch Network Switch

＞ Support 8 gigabit ports
＞ Support IEEE802.3/802.3u/802.3x store and forward mode
＞ Support full/half duplex, MDI/MDI-X adaptive function
＞ Support high backplane bandwidth, large capacity cache, and ensure port wire speed forwarding
＞ Support broadcast storm suppression function to improve network stability
＞ Wide voltage DC power supply, non-polar power supply design
＞ - 40 ° C~+75 ° C wide temperature design ensures that the equipment can adapt to various harsh site environments
＞ IP40 level protection, corrugated high-strength metal shell, fanless, low power consumption design
＞ lEC CIass. A electromagnetic protection level, ultra-high EMC

A layer 2 switch is a type of network switch or device that works on the data link layer (OSI Layer 2) and utilizes MAC Address to determine the path through where the frames are to be forwarded. It uses hardware based switching techniques to connect and transmit data in a local area network (LAN).

A layer 2 switch requires MAC address of NIC on each network node to transmit data. They learn MAC addresses automatically by copying MAC address of each frame received, or listening to devices on the network and maintaining their MAC address in a forwarding table. This also enables a layer 2 switch to send frames quickly to destination nodes.

HS3000-3008 Layer 2 Managed Gigabit Industrial Switch Network Switch is a managed industrial Ethernet switch that meets the requirements of industrial design. It adopts mature technology and open network standards, with a compact shape, visual WEB management, and simple and clear operation. The whole series adopts a new generation of Ethernet chips and innovative architecture design to achieve the lowest energy consumption for accessing dry megaswitch, bringing green, environment-friendly and energy-saving products to users. It is suitable for low temperature and high temperature, strong electromagnetic interference resistance, salt fog resistance, earthquake resistance and shake resistance. It is equipped with DC power supply to provide an efficient, reliable and fast solution for the industrial Internet of Things.

Interface information

Gigabit electrical ports: up to 8 10/100/1000Base-T (X) RJ45 interfaces

Power interface: DC JACK interface

Environmental requirements

Operating temperature: - 40 ° C~+75 ° C

Storage temperature: - 40 ° C~+85 ° C

Relative humidity: 5%~95% (non condensing)

MTBF: 100000 hours

Swap Properties

MAC address table: 2K

Forwarding method: store and forward

Cache size: 1M

Mechanical structure

External dimension: 160mm (H) x 105mm (D) x 28mm (W)

Installation mode: desktop type, rack type, DIN card rail type optional

Weight: ＜ 300g

Protection grade: IP40

Transmission distance:

Twisted pair: 100M (standard CAT5/CAT5e cable)

Power requirements

Working voltage: DC12~48V (rated input)

Power consumption of the whole machine<5W

Software features

Multicast support: support IGMP Snooping

VLAN: support IEEE 802.1 Q4K VLAN

QOS: supports COS, DSCP, 4 queues, and WRR HQ WRR dispatching mode

Diagnostic maintenance: supports port mirroring and system logs

Ports: support viewing all port statistics, resetting port statistics, and simple port interworking settings

Management function: support WEB, SNMP management mode, support configuration management

Alarm management: support TRAP alarm

Security functions: support IEEE802.1X, hierarchical user management, ACL access control list, and port based MAC filtering/binding

Data control: support port speed limit based on ingress/egress, support half duplex back pressure flow control and 802.3X full duplex flow control, and support storm suppression based on broadcast, multicast, and unknown unicast

Key control: support one key restart, one key restore factory settings

Indicator lights

Power indicator: PWR

Port status indicator/port connection status indicator: optical port LINK/SPD indicator, electrical port ACT/SPD indicator
